Descripción
FABRICANTE FAIRCHILD/ONSEMI
Data Selectors/Multiplexers
Selectores de datos/multiplexores General DescriptionThese data selectors/multiplexers contain full on-chipdecoding to select the desired data source. The DM74150selects one-of-sixteen data sources. The DM74150 has astrobe input which must be at a LOW logic level to enablethese devices. A HIGH level at the strobe
forces the W out-put HIGH and the Y output (as applicable) LOW.The DM74150 features an inverted (W) output only.Features¦150 selects one-of-sixteen data lines¦Performs parallel-to-serial conversion¦Permits multiplexing from N lines to one line¦Also for use as Boolean function generator¦Typical average propagation delay time, data input to Woutput:11 ns¦Typical power dissipation: 200 mW
