Descripción
Mfr Package Description PLASTIC, MS-011AB, DIP-28
Status Discontinued
Converter Type ADC, DUAL-SLOPE
JESD-30 Code R-PDIP-T28
JESD-609 Code e0
Linearity Error-Max (EL) 0.0122 %
Negative Supply Voltage-Nom -15.0 V
Number of Analog In Channels 1.0
Number of Bits 4
Number of Functions 1
Number of Terminals 28
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Output Bit Code BINARY CODED DECIMAL
Output Format PARALLEL, 4 BITS
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Shape RECTANGULAR
Package Style IN-LINE
Qualification Status Not Qualified
Seated Height-Max 6.35 mm
Supply Voltage-Nom 5.0 V
Surface Mount NO
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Length 37.4 mm
Width 15.24 mm
